OPTICAL SENSOR

PYTHON 0.3/0.5/1.3 Megapixel Global Shutter CMOS Image Sensors

        - SXGA: 1280 X 1024 Active Pixels, 1/2" Optical Format

          SXGA: 800 X 600 Active Pixels, 1/3.3" Optical Format

          SXGA: 640 X 480 Active Pixels, 1/4" Optical Format

        - 4.8μm X 4.8μm Low Noise Global Shutter Pixels with In-pixel CDS

        - Monochrome (SN) or Color (SE)

        - Zero ROT Mode Enabling Faster Frame Rate

        - Frame Rate at Full Resolution (LVDS)

          210/175 frames per second @ SXGA (Zero ROT/ Normal ROT)

          560/420 frames per second @ SVGA (Zero ROT/ Normal ROT)

          860/620 frames per second @   VGA (Zero ROT/ Normal ROT)

        - 43 Frames per Second (fps) at Full Resolution (CMOS)

        - On-chip 10-bit Analog-to-Digital Converter (ADC)

        - 8-bit or 10-bit Output mode

        - Four/Two/One Low Voltage Differential Signaling (LVDS)

          High Speed Serial Outputs or Parallel CMOS Output

        - Random Programmable Region of Interest (ROI) Readout

        - Seriaol Peripheral Interface (SPI)

        - Automatic Exposure Control (AEC)

        - Phase Locked Loop (PLL)

        - High Dynamic Range (HDR) up to n90dB

        - Dual Power Supply (3.3V and 1.8V)

        - -40℃ to +85℃ Operational Temperature Range

        - 48-pin LCC and Bare Die

        - 590mW Power Dissipation (LVDS)

        - 375mW power Dissipation (CMOS)

        - These Devices are Pb-Free and are RoHS Compliant

STEREO VISION SENSOR

GOLF SWING ANALYSIS SYSTEM
